Product Details:
|
| Name: | Shank Adapter | Use: | Masonry Drilling,rock Drilling |
|---|---|---|---|
| Material: | High Carbon Steel,Tungsten Carbide | Certification: | ISO9001 |
| Process: | Forging,Milled | Quality: | Stable And Reliable |
| Application: | Drilling Holes,marble Granite Title | Machine Type: | Drilling Tools |
| Highlight: | T45 Thread Shank Adapter,Masonry Drilling Shank Adapter,T38 Thread Shank Adapter |
||
Shank adapter is used for transmitting power from the rock drill to the drill stems, as well as rotation torque, into the drill string without energy losses. Male shank adapter are generally suited for drifting, tunneling and extension applications where high stresses are present. Female shank adapters are used when the drilling space is limited. Top quality of alloy steels, CNC machining and advanced heat treatment ensure Minetech’s reliable quality.
Rock drill brand: Atlas Copco, Tamrock, Ingersoll, Boart Longyear, Furukawa, Montabert, Soonsan.
Thread size: R25, R28, SSR28, R32, SSR32, R35, SSR35, R38, T38, T45, T51, GT60.
| Product Name | Shank Adapter |
| Thread | T38 |
| Model Number | COP1638 |
| Length | 525mm |
| Diameter | 38mm |
| Weight | 4.5KG |
| Usage | Long hole drilling |
