Product Details:
|
| Certification: | ISO9001 | Product Name: | Diamond Core Drill Bit |
|---|---|---|---|
| Size: | AQ | Length: | 1.5 - 3m |
| OD Thickness: | 44.5 X 4.8mm | Material: | Diamond,65Mn |
| Use: | Exploration Of Mines, Wells, Roads And Bridges, Geological | Application: | Drilling Holes |
| Packing: | Plastic Box,diamond Core Drill Bits Packed By Box Or Carton | Machine Type: | Drilling Tool |
| Advantage: | High Drilling Efficiency | Color: | Customized |
| High Light: | 65Mn geological drill pipe,1.5m geological drill pipe |
||
AQ Drill Pipe For Prospecting, Drilling Wells Highway Brid Core Drilling Tools
Product information:
Core diamond drilling tool for drilling rock in underground soil formations which includes an outside pipe and an inside pipe therein that can be conveyed separately to the surface.
The inside pipe includes a core-receiving receptacle at its lower end, and at its upper end is provided with a measurement unit for on-site acquisition, processing and storage of data, such as borehole, core and/or drilling process parameters.
Application:
Core drilling bits are mainly tools used to drill holes in steel plates and other products, hollow core bits are used in conjunction with machines that are specifically on core drilling bits. Thin-walled diamond core drill bits: concrete core samples are drilled directly into the structural concrete and processed for compressive strength testing, this method is recognised as a more intuitive and reliable test method for testing the strength of concrete
Q(C) Series Drill Rod Specifications:
|
No. |
item |
length(m) |
OD*thickness(mm) |
depth(m) |
|
1 |
AQ |
1.5 |
44.5*4.8 |
300 |
|
2 |
AQ |
3.0 |
44.5*4.8 |
300 |
|
3 |
BQ (BC) |
1.5 |
55.7*4.8 |
600 |
|
4 |
BQ (BC) |
3.0 |
55.7*4.8 |
1200 |
|
5 |
NQ (NC) |
1.5 |
70.5*5.0 |
600 |
|
6 |
NQ (NC) |
3.0 |
70.5*5.0 |
1200 |
|
7 |
HQ (HC) |
1.5 |
89.0*5.6 |
600 |
|
8 |
HQ (HC) |
3.0 |
89.0*5.6 |
1200 |
|
9 |
PQ (PC) |
1.5 |
114.3*6.2 |
600 |
|
10 |
PQ (PC) |
3.0 |
114.3*6.2 |
1200 |
|
11 |
SQ |
1.5 |
139.7*7.1 |
300 |
|
12 |
SQ |
3.0 |
139.7*7.1 |
600 |
Advantages:
Professional Team And Experience.
Selected High Quality Raw Materials.
Safe Package And Shipment.
Best After-Sale Service.
Package:
Carton case,or as customer request.
