PQ3 NQ3 BQ3 Diamond Core Drill Bit for Geological Drilling with High Efficiency

Large Image : PQ3 NQ3 BQ3 Diamond Core Drill Bit for Geological Drilling with High Efficiency

Product Details:

Place of Origin:	CHINA
Brand Name:	MTH
Certification:	ISO9001
Model Number:	HQ

Payment & Shipping Terms:

Minimum Order Quantity:	1 Piece
Price:	$3-$300
Packaging Details:	wooden case
Delivery Time:	10-15 days
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	10000 pieces per month

Contact Now

PQ3 NQ3 BQ3 Diamond Core Drill Bit for Geological Drilling with High Efficiency

Description

Name:	Diamond Core Drill	Material:	Diamond,65Mn
Type:	Core Drill Bit	Use:	Masonry Drilling,Well Drilling,Concret Etc.
Application:	Drilling Holes	Size:	PQ,HQ,AQ,BQ,NQ
Product Name:	Diamond Segment,Diamond Core Drill,diamond Drill Bit	Certification:	ISO9001
Packing:	Plastic Box,diamond Core Drill Bits Packed By Box Or Carton	Machine Type:	Drilling Tool
Advantage:	High Drilling Efficiency,High-efficiency	Package:	In Wooden Case
Highlight:	65Mn diamond bit drill bit , HQ diamond bit drill bit , ISO9001 diamond bit drill bit

Geological Drilling HQ Diamond Core Drilling Tools for Measurement and Processing

Product Description

Core diamond drilling tool for drilling rock in underground soil formations which includes an outside pipe and an inside pipe that can be conveyed separately to the surface. The inside pipe features a core-receiving receptacle at its lower end and a measurement unit at its upper end for on-site acquisition, processing, and storage of data including borehole, core, and drilling process parameters.

Specifications

Size	Outside diameter (mm)	Inside diameter (mm)
AQ	47.75/47.50	27.10/26.85
BQ	59.69/59.44	36.52/36.27
BQ3	59.69/59.44	33.65/33.40
NQ	75.44/75.19	47.75/47.50
NQ2	75.44/75.19	50.80/50.55
NQ3, NQTT	75.44/75.19	45.21/44.96
HQ	95.76/95.38	63.63/63.38
HQ3, HQTT	95.76/95.38	61.24/60.99
PQ	122.30/121.80	85.09/84.84
PQ3	122.30/121.80	83.18/82.93

Product Images
