76mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining

76mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining
76mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining 76mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining 76mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining 76mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining

Large Image :  76mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining

Product Details:
Place of Origin: CHINA
Brand Name: MTH
Certification: ISO 9001
Model Number: 76mm T45
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: $3-$300
Packaging Details: wooden case
Delivery Time: 10-15 days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 20000 pieces per month
Contact Now

76mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining

Description
Product Name: Thread Button Bit Color: Blue/yellow / Black / Red
Processing Type: Forging Rock Formation: Hard / Medium Hard / Soft Rock Formation
Thread: T45 Weight: 2.4KG
Carbide Shape: Spherical Usage: Mining Or Quarry Or Well Drilling, Rock Drilling, For Drifting Tunneling Bench Drilling, Hole Drilling, Coal Miniing
Flushing Holes: 3 Place Of Origin: China
Button: 13 Buttons Diameter: 76mm
Highlight:

76mm thread button bit

,

mining forging thread button bit

,

threaded tungsten carbide button bits

76mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining





Description:



1. Raw material: It is produced by premium alloy steel bar and tungsten carbides with heat treatment

2. Body & button shape: Normal and retract type;ballistic and spherical

3. Face shape: General flat and drop-center

4.Thread type: R32,T38,T45,T51

5. Diameter: 41mm-127mm



A comprehensive range of various button bits shown as below:



R32
Name Diameter Tip size(mm) Flushing holes
mm gauge front side front
R32 trhead button bits 41 4*9 2*8 1 1
43 4*9 2*9 1 1
45 4*10 2*9 1 1
R32 Retrac thread button bits 60 6*9 4*8 0 3
64 6*9 4*9 0 3
70 6*10 4*10 0 3
T38
Name Diameter Tip size(mm) Flushing holes
mm gauge front side front
T38 trhead button bits 57 5*11 3*10 1 1
64 5*12 3*11 1 1
76 5*14 3*12 1 2
T38 Retrac thread button bits 60 8*9 3*9 2 2
64 8*9 4*9 2 2
70 8*10 4*10 2 2
76 8*11 4*10 2 2
89 8*12 5*12 2 2
T45
Name Diameter Tip size(mm) Flushing holes
mm gauge front side front
T45 trhead button bits 70 6*11 4*10 0 2
76 6*13 4*10 0 2
89 8*12 5*12 2 2
102 8*13 6*12 2 2
115 8*14 6*13 2 2
T45 Retrac thread button bits 70 8*11 4*10 2 2
76 8*11 4*10 2 2
80 8*12 5*11 2 2
89 8*12 6*11 2 2
102 8*13 6*12 2 2
T51
Name Diameter Tip size(mm) Flushing holes
mm gauge front side front
T51 trhead button bits 89 8*12 5*12 2 2
102 8*13 6*12 2 2
115 8*14 6*13 2 2
127 8*14 6*14 2 2
T51 Retrac thread button bits 89 8*11 5*12 2 2
102 8*11 6*12 2 2
115 8*12 6*13 2 2
127 8*12 6*14 2 2



Our advantage:



• Competitive price:
• Problems solve ability
• Fast delivery time
• Best quality control
• OEM,ODM service
• Best after serviec



Features:



• Cheap price because of direct factory price
• Usually it takes 30 days for production. only 2 or 3 days if we have stock of your request size.
• We have our own experienced QC team,there will be strict inspection and testing for every order before shipping out.
• Your own request about product will be served well
• We will go to your place to check and solve the problems if there



76mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining 076mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining 176mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining 276mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining 376mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining 476mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining 5

76mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining 676mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining 776mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining 876mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining 9

76mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining 1076mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining 1176mm T45 Normal Skirt Thread Button Bit Forging For Understand Mining 12
