Product Details:
|
Product Name: | T45 102mm Thread Drill Bits | Color: | Blue And Others |
---|---|---|---|
Thread: | T45 | Rock Formation: | Hard / Medium Hard / Soft Rock Formation |
Diameter: | 102mm | Usage: | Mining Or Quarry Or Well Drilling, Rock Drilling, For Drifting Tunneling Bench Drilling, Hole Drilling, Coal Miniing |
Weight: | 6KG | Flushing Holes: | 2 Or Optional |
Carbide Shape: | Ballistic/spherical/semi-ballistic | Processing: | CNC Milling And Proprietary Heat Treatment Process |
Highlight: | forging threaded button bits,102mm t45 threaded button bits,threaded drilling button bit |
Description:
Raw material: It is produced by premium alloy steel bar and tungsten carbides with heat treatment
Body & button shape: Normal and retract type;ballistic and spherical
Face shape: General flat and drop-center
A comprehensive range of various button bits shown as below:
R32 | |||||
Name | Diameter | Tip size(mm) | Flushing holes | ||
mm | gauge | front | side | front | |
R32 trhead button bits | 41 | 4*9 | 2*8 | 1 | 1 |
43 | 4*9 | 2*9 | 1 | 1 | |
45 | 4*10 | 2*9 | 1 | 1 | |
R32 Retrac thread button bits | 60 | 6*9 | 4*8 | 0 | 3 |
64 | 6*9 | 4*9 | 0 | 3 | |
70 | 6*10 | 4*10 | 0 | 3 | |
T38 | |||||
Name | Diameter | Tip size(mm) | Flushing holes | ||
mm | gauge | front | side | front | |
T38 trhead button bits | 57 | 5*11 | 3*10 | 1 | 1 |
64 | 5*12 | 3*11 | 1 | 1 | |
76 | 5*14 | 3*12 | 1 | 2 | |
T38 Retrac thread button bits | 60 | 8*9 | 3*9 | 2 | 2 |
64 | 8*9 | 4*9 | 2 | 2 | |
70 | 8*10 | 4*10 | 2 | 2 | |
76 | 8*11 | 4*10 | 2 | 2 | |
89 | 8*12 | 5*12 | 2 | 2 | |
T45 | |||||
Name | Diameter | Tip size(mm) | Flushing holes | ||
mm | gauge | front | side | front | |
T45 trhead button bits | 70 | 6*11 | 4*10 | 0 | 2 |
76 | 6*13 | 4*10 | 0 | 2 | |
89 | 8*12 | 5*12 | 2 | 2 | |
102 | 8*13 | 6*12 | 2 | 2 | |
115 | 8*14 | 6*13 | 2 | 2 | |
T45 Retrac thread button bits | 70 | 8*11 | 4*10 | 2 | 2 |
76 | 8*11 | 4*10 | 2 | 2 | |
80 | 8*12 | 5*11 | 2 | 2 | |
89 | 8*12 | 6*11 | 2 | 2 | |
102 | 8*13 | 6*12 | 2 | 2 | |
T51 | |||||
Name | Diameter | Tip size(mm) | Flushing holes | ||
mm | gauge | front | side | front | |
T51 trhead button bits | 89 | 8*12 | 5*12 | 2 | 2 |
102 | 8*13 | 6*12 | 2 | 2 | |
115 | 8*14 | 6*13 | 2 | 2 | |
127 | 8*14 | 6*14 | 2 | 2 | |
T51 Retrac thread button bits | 89 | 8*11 | 5*12 | 2 | 2 |
102 | 8*11 | 6*12 | 2 | 2 | |
115 | 8*12 | 6*13 | 2 | 2 | |
127 | 8*12 | 6*14 | 2 | 2 |
Applications:
Mining or Quarry or Well Drilling, Rock Drilling, for drifting tunneling bench drilling, Hole drilling, Coal Miniing
Advantage:
• Competitive price
• Problems solve ability
• Fast delivery time
• Best quality control
Company Profile:
Hebei Minetech Machinery Technology Co, Ltd. is an joint venture enterprise with Europe Partner, which is located in Shijiazhuang City, Hebei Province,China. Our company is specialized in manufacturing and exporting of mining machinery, such as hydraulic and pneumatic drill machine, roof bolter and drilling consumption, like drill bit and drill rod with own factory in Shijiazhuang City.
With our rich expenience for over a decade and with professional engineers andsales team, we focus on providing complete solutions for mining machinery.
Target markets is gradually shifted from domestic market to international market, products are exported to more than thirty countries and regions, including Southeast Asia, the United States, Germany, Britain, South Africa, Poland, Russia, Middle Asia, South America and so on, and established a good brand and reputation international market.
