Blasting Yt28 Drilling Rock Drilling Machine With Air Leg

Blasting Yt28 Drilling Rock Drilling Machine With Air Leg
Blasting Yt28 Drilling Rock Drilling Machine With Air Leg
Blasting Yt28 Drilling Rock Drilling Machine With Air Leg Blasting Yt28 Drilling Rock Drilling Machine With Air Leg

Large Image :  Blasting Yt28 Drilling Rock Drilling Machine With Air Leg

Product Details:
Place of Origin: CHINA
Brand Name: MTH
Certification: ISO 9001
Model Number: YT28
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: Wooden case
Delivery Time: 7-15 woring days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 2000 sets per week
Contact Now

Blasting Yt28 Drilling Rock Drilling Machine With Air Leg

Description
Name: Rock Drill Machine Machine Type: Drilling Tools
Model: YT28 Application: Mountain Cutting, Rock Drilling
Feature: High Drilling Efficiency Weight: 26.5kg
Type: ROCK DRILLING RIG Advantage: Low Price, High Efficiency
Drilling And Frequency: ≥37Hz Usage: Mining Used
Key Words: Rock Drilling Machine
Highlight:

yt28 drilling rock machine

,

blasting drilling rock machine

,

blasting mining rock drilling machine

Rock Drills YT28 With Air Leg Rock Drilling Machine





Rock Drilling Machine Product Information:



1. YT series pneumatic rock drill for drilling in the hard rock horizontal and inclined direction hole, it can also be up drilling anchor hole, hole diameter is Φ 35 ~ 45 mm, and effective drilling depth of 5 meters. It may also working for roof bolting holes. The rock drill played an important role in mining, quarrying and tunneling projects.
2. Depending on the roadway cross-section size and operation conditions, the machine can be used FT160A gas legs, long FT160C type gas type, FT160B dispirited legs (metal mines can also be used FT170 gas leg), can also be installed in jumbo or drill the rack to dry and wet drilling.



Rock Drilling Machine Specifications:



PRODUCT SPECIFICATION
The parameter name Unit The parameter value
Weight kg ≈26.5
Length mm 661
The cylinder diameter mm 82
Piston stroke mm 60
Gas consumption L/s ≤65
Drilling and frequency Hz ≥37
Impact energy J ≥70
borehole speed mm/min ≥475
The borehole diameter mm Φ34-45
Perforating depth m 5
Shank mm 22×108±1



Rock Drilling Machine Features:



Low price, high efficiency.



Rock Drilling Machine Application:



Mountain cutting, rock drilling.



Blasting Yt28 Drilling Rock Drilling Machine With Air Leg 0Blasting Yt28 Drilling Rock Drilling Machine With Air Leg 1Blasting Yt28 Drilling Rock Drilling Machine With Air Leg 2

                                                                          FAQ

Q1: What’s your delivery time?
A: Commonly product need 20 days to produce, within 3 days if in stock.
Q2: What’s methods of payments are accepted?
A: We agree T/T ,L/C ,West Union ,One touch ,Money Gram ,Paypal.
Q3: What about the Shipments?
A: Bases on other quantity .We can send it to you by Express ,by Air ,by Sea ,and by Train.Or send the goods to your Chinese agent.
Q4: How to control the quality?
A: We should be checking & testing everyone button bit before shipment.
Q5: Do you agree sample order ?
A: Yes ,we are welcome your sample order to testing our quality.
Q6: Can we select the button bit color?
A: Yes ,we have golden ,silvery ,black and blue for your choice.
Q7: Can we change to our mark on the button bit?
A: Yes ,we can casting your company mark on the button bit.(Except sample order)
Q8: Do you have after-sale service and warranty service ?
A: Any Quality or quantity problem once confirmed,we will be compensate you the same. Any question or problem we will be reply you within 24 hours.
Q9: Can I trust your company ?
A: Our company has been certificated by Chinese government ,and verified by Ali baba Trade Assurance. 100% refund of the Trade Assurance Amount .Ali baba can guarantee all of you payment .Just order from US !
