Well Drill Rigs DHD350 5Inch Down The Hole Hammer Anticorrosive

Well Drill Rigs DHD350 5Inch Down The Hole Hammer Anticorrosive
Well Drill Rigs DHD350 5Inch Down The Hole Hammer Anticorrosive Well Drill Rigs DHD350 5Inch Down The Hole Hammer Anticorrosive

Large Image :  Well Drill Rigs DHD350 5Inch Down The Hole Hammer Anticorrosive

Product Details:
Place of Origin: CHINA
Brand Name: MTH
Certification: ISO9001
Model Number: 5 Inch
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: $3-$300
Packaging Details: wooden case
Delivery Time: 10-15 days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 10000 pieces per month
Contact Now

Well Drill Rigs DHD350 5Inch Down The Hole Hammer Anticorrosive

Description
Product Name: DTH Hammer Size: 5 Inches
Connect Thread: API 2 3 / 8 REG Brand Name: MTH
Machine Type: Drilling Tool,Drilling Equipment Material: Carbon Steel,Tungsten Carbide & Steel
Application: Rock Drilling,quarry,water Well Drilling,mining Or Welling Drilling Color: Blue,Gold,Red,blue Or Customized
Processing Type: Forging,Casting Advantage: High Performance,High Wear Resistant,High-efficiency
Highlight:

DHD350 5Inch Down The Hole Hammer

,

Down The Hole Hammer Anticorrosive

,

DHD350 5Inch drill rig hammer

Well Drill Rigs DHD350  5 Inch Down The Hole Hammer





Application:



Be used for drilling in mining, quarrying, exploration, water-well, geothermal, and construction / geotechnical projects



Description:



“DTH” is the short for “Down The Hole” and sometimes it is also called “RAB” in some markets, “RAB” is short for “Rotary Air Blasting”.



Specifications:



Technical Data

Length(Without Bit)

930mm

1030mm

1214mm

1160mm

1248mm

Weight(Without Bit)

25.00 kg

39.00 kg

76.50 kg

72.50 kg

100.00 kg

External Diameter

82mm

99mm

126mm

126mm

142/144/146/148mm

Bit Shank

DHD3.5

COP44/DHD340

COP54/DHD350R

ND55C/DHD350Q

COP64/DHD360

Hole Range

90-110 mm

110-135 mm

135-155 mm

135-155 mm

155-190 mm

Connect ion Thread

API 2 3/8”Reg

API 2 3/8”Reg

API 2 3/8”Reg

API 3 1/2”Reg

API 2 7/8”Reg

API 2 3/8”Reg

API 3 1/2”Reg

API 2 7/8”Reg

API 3 1/2”Reg



Working Pressure

1.0- 1.5 Mpa

1.2-2.0 Mpa

1.3-2.3Mpa

1.3-2.3 Mpa

1.5-2.5 Mpa

Inpact Rate at 17 Bar

28HZ

27HZ

25HZ

25HZ

23HZ

Reccfurended Rotation Speed

25-40 "min

25-40 r/min

20-35 r/min

20-35 r/min

20-30 r/min

Air Consunption

1.0Mpa :4.5 m3/min

1.0Mpa :6m3/min

1.0Mpa:9 m3/min

1.0Mpa:9m3/min

1.0Mpa :10 m3/min

1.5Mpa:9.0m3/min

1.8Mpa:10m3/min

1.8Mpa:15m3/min

1.8Mpa:15m3/min

1.8Mpa:20m3/min



2.4Mpa:15m3/min

2.4Mpa:23m3/min

2.4Mpa:23m3/min

2.4Mpa:28.5m3/mi



Package:



Wooden case



Features:

1. Simple and reasonable design, easy to assemble and dis-assemble, low problem rate.
2. Low air consumption, smooth drilling, maximum impact power, high penetration rate.
3. Multiple precise heat-treatment with all hammer parts to provide longest lifespan under roughest working conditions.





Well Drill Rigs DHD350 5Inch Down The Hole Hammer Anticorrosive 0Well Drill Rigs DHD350 5Inch Down The Hole Hammer Anticorrosive 1Well Drill Rigs DHD350 5Inch Down The Hole Hammer Anticorrosive 2Well Drill Rigs DHD350 5Inch Down The Hole Hammer Anticorrosive 3





Well Drill Rigs DHD350 5Inch Down The Hole Hammer Anticorrosive 4Well Drill Rigs DHD350 5Inch Down The Hole Hammer Anticorrosive 5
