High Air Pressure DTH Hammer DHD350 COP54 HD55 for Mining and Well Drilling

High Air Pressure DTH Hammer DHD350 COP54 HD55 for Mining and Well Drilling
High Air Pressure DTH Hammer DHD350 COP54 HD55 for Mining and Well Drilling
High Air Pressure DTH Hammer DHD350 COP54 HD55 for Mining and Well Drilling High Air Pressure DTH Hammer DHD350 COP54 HD55 for Mining and Well Drilling High Air Pressure DTH Hammer DHD350 COP54 HD55 for Mining and Well Drilling High Air Pressure DTH Hammer DHD350 COP54 HD55 for Mining and Well Drilling High Air Pressure DTH Hammer DHD350 COP54 HD55 for Mining and Well Drilling

Large Image :  High Air Pressure DTH Hammer DHD350 COP54 HD55 for Mining and Well Drilling

Product Details:
Place of Origin: CHINA
Brand Name: MTH
Certification: ISO9001
Model Number: TRC 90
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: $3-$300
Packaging Details: wooden case
Delivery Time: 10-15 days
Payment Terms: T/T,Western Union,MoneyGram
Supply Ability: 10000 pieces per month
Contact Now

High Air Pressure DTH Hammer DHD350 COP54 HD55 for Mining and Well Drilling

Description
Product Name: DTH Hammer Diameter: 90-100MM
Air Pressure: 0.5-0.7MPa Length: 855mm
Use: Ore Mining,Well Drilling,DTH Drilling Material: Carbon Steel,Tungsten Carbide & Steel
Application: Rock Drilling,quarry,water Well Drilling,mining Or Welling Drilling Color: Blue,Gold,Red,black Or Customized
Advantage: High Performance,High Wear Resistant,High-efficiency Usage: Hole Drilling,oil,water Well,Underground Mining,ore
Weight: 22kg Package: Wooden Case
Highlight:

Dth Hammer DHD350

,

Dth Hammer COP54

,

COP54 Mining Spare Parts

High Air Pressure DTH Hammer DHD350 COP54 HD55 Mining Spare Parts
"DTH" stands for "Down The Hole" and is sometimes called "RAB" (Rotary Air Blasting) in certain markets. The DTH hammer is a critical component in down hole drilling applications, regardless of rock type, hole depth, or drilling rig used. High-quality submersible DTH hammers are characterized by their durability, accuracy, and manageability.
Specifications
Parameter Value
Length (without bit) 1209mm
Weight (without bit) 77.5Kg
External Diameter φ148mm
Bit Shank DHD340 COP44 HD45 QL40 MISSION40 SD4
Hole range φ130-φ216mm
Connection Thread API 2 3/8" Reg API 3 1/2" Reg
Working Pressure 1.0-2.5Mpa
Impact rate at 1.5Mpa 27HZ
Recommended rotation speed 25-40r/min
Air consumption 6m³/min (1.0Mpa)
10m³/min (1.8Mpa)
14m³/min (2.4Mpa)
Applications
  • Rock Drilling
  • Quarry operations
  • Water well drilling
  • Mining operations
  • Construction blasting
  • Well drilling
Key Advantages
  • Extended operating life
  • Excellent anti-wear properties
  • Easy to operate
  • Stable and reliable performance
  • Smooth operation with high efficiency
High Air Pressure DTH Hammer DHD350 COP54 HD55 for Mining and Well Drilling 0 High Air Pressure DTH Hammer DHD350 COP54 HD55 for Mining and Well Drilling 1 High Air Pressure DTH Hammer DHD350 COP54 HD55 for Mining and Well Drilling 2 High Air Pressure DTH Hammer DHD350 COP54 HD55 for Mining and Well Drilling 3
