YT29A Air Leg Rock Drilling Machine with 22×108 Mm Shank and 659x248x205mm Dimensions for Integral Muffler Operation

YT29A Air Leg Rock Drilling Machine with 22×108 Mm Shank and 659x248x205mm Dimensions for Integral Muffler Operation
YT29A Air Leg Rock Drilling Machine with 22×108 Mm Shank and 659x248x205mm Dimensions for Integral Muffler Operation YT29A Air Leg Rock Drilling Machine with 22×108 Mm Shank and 659x248x205mm Dimensions for Integral Muffler Operation YT29A Air Leg Rock Drilling Machine with 22×108 Mm Shank and 659x248x205mm Dimensions for Integral Muffler Operation YT29A Air Leg Rock Drilling Machine with 22×108 Mm Shank and 659x248x205mm Dimensions for Integral Muffler Operation

Large Image :  YT29A Air Leg Rock Drilling Machine with 22×108 Mm Shank and 659x248x205mm Dimensions for Integral Muffler Operation

Product Details:
Place of Origin: China
Brand Name: Rock Drilling Machine
Certification: IOS9001
Model Number: YT29A
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $3-$300
Packaging Details: Wooden case
Delivery Time: Within 2 weeks
Payment Terms: T/T
Supply Ability: 1000/month

YT29A Air Leg Rock Drilling Machine with 22×108 Mm Shank and 659x248x205mm Dimensions for Integral Muffler Operation

Description
Product Name: Rock Drilling Machine Application: Coal Mining, Quarrying, Tunneling
Shank Dimensions(hex×length): 22×108 Mm±108mm Weight: 27kg
Power Type: Air Condition: New
Air Pressure: 0.4—0.63MPa Overall Dimensions (L*W*H): 659x248x205mm
Drilling Depth: 5m-20m Drilling Hole Diameter: 34-45mm
Highlight:

Coal Mining Rock Drilling Machine

,

Small Hole Rock Drilling Machine

,

YT29A Rock Drilling Machine

YT29A Air Leg Rock Drilling Machine For Small Hole Drilling And Coal Mining
Product Description
The YT29A air leg rock drilling machine is designed for drilling horizontal or tip-tilted blastholes in solid rocks as well as vertical bolt holes on the roof. This machine can be used with the air leg FT160A or FT160B and can also be installed on drill rigs or drill frames. It includes a transparent lubricator FY250 to monitor oil levels and adjust oil quantity for optimal lubrication. This machine is essential for mining, railway, transportation, water conservancy construction, and earthwork projects.
Features
  • Easily-accessible position throttle
  • Integral muffler for lower noise
  • Reliable structure for easy and stable operation
  • Compatible with hand-held and air legs rock drills
  • Provides the ultimate combination of performance and economy
Technical Parameters
Product Rock Drilling Machine
Shank dimensions (hex×length) 22×108 Mm±108mm
Weight 27kg
Air Pressure 0.4--0.63MPa
Warranty 1 Year
Application Surface Mining, Quarrying, Construction
Power Type Pneumatic, Air Compressor
Air consumption ≤88 L/S (0.63MPa)
Water pipe (inner dia) 13mm
Piston stroke 60mm
Condition New
Applications
Pusher legs and stoper rock drills cover all construction, tunnelling, and mining applications in different rock formations. They are robustly designed with high impact energy and low air consumption. All rock drills feature water flushing, rifle bar rotation, and pusher leg control at the back head. An in-line lubricator is included with each rock drill. Together with the appropriate pusher leg, the rock drill forms a cost-effective drilling unit, widely used in coal mining, tunnelling, and quarrying.
Packing and Shipping

Packing: The Rock Drill and the Pusher leg are packed separately in a carton box.

Shipping: Small quantities are shipped by express, while large quantities are shipped by sea. Shipping costs are based on the quantity ordered.

Company Profile
Hebei Minetech Machinery Technology Co, Ltd. is a joint venture enterprise with a European partner, located in Shijiazhuang City, Hebei Province, China. The company specializes in manufacturing and exporting mining machinery, including hydraulic and pneumatic drill machines, roof bolters, and drilling consumables like drill bits and drill rods. With over a decade of experience and a team of professional engineers and sales staff, we provide complete solutions for mining machinery. Our products are exported to more than thirty countries and regions, including Southeast Asia, the United States, Germany, Britain, South Africa, Poland, Russia, Middle Asia, and South America, establishing a strong international reputation.
YT29A Air Leg Rock Drilling Machine with 22×108 Mm Shank and 659x248x205mm Dimensions for Integral Muffler Operation 0 YT29A Air Leg Rock Drilling Machine with 22×108 Mm Shank and 659x248x205mm Dimensions for Integral Muffler Operation 1 YT29A Air Leg Rock Drilling Machine with 22×108 Mm Shank and 659x248x205mm Dimensions for Integral Muffler Operation 2 YT29A Air Leg Rock Drilling Machine with 22×108 Mm Shank and 659x248x205mm Dimensions for Integral Muffler Operation 3
