Handheld Gasoline Power YN27C Internal Combustion Rock Drill For Mine Or Quarry

Handheld Gasoline Power  YN27C Internal Combustion Rock Drill For Mine Or Quarry
Handheld Gasoline Power  YN27C Internal Combustion Rock Drill For Mine Or Quarry
Handheld Gasoline Power  YN27C Internal Combustion Rock Drill For Mine Or Quarry Handheld Gasoline Power  YN27C Internal Combustion Rock Drill For Mine Or Quarry Handheld Gasoline Power  YN27C Internal Combustion Rock Drill For Mine Or Quarry

Large Image :  Handheld Gasoline Power YN27C Internal Combustion Rock Drill For Mine Or Quarry

Product Details:
Place of Origin: China
Brand Name: Minetech
Certification: ISO9001
Model Number: YN27C Handheld Rock Drill
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: 1/carton
Delivery Time: 15-30 days
Payment Terms: Western Union, MoneyGram, T/T, L/C
Supply Ability: 30000 pieces per month

Handheld Gasoline Power YN27C Internal Combustion Rock Drill For Mine Or Quarry

Description
Product Name: Jack Hammer Drill Key Words: YN27C Rock Drill
Model Type: YN27C Color: Yellow
Package: Wooden Case Processing Type: Forging
Machine Type: Rock Drill Rig Application: Bolting, Drifting • Bench Drilling • Production Drilling
Port: Tianjin Qingdao
Highlight:

Handheld Gasoline Power Rock Drill

,

Mine Rock Drill

,

Internal Combustion Rock Drill

Handheld Gasoline Power YN27C Internal Combustion Rock Drill for Mine or Quarry



Product Description



YN27 Inter Combustion Gasoline Rock Drill is a very efficient rock drilling machine, composed of gasoline engine, air pump, rock drill. It adapts to these outside situations without water and electronic power. Meanwhile it is a hand- held drill, during operation, rock power is blown away by the compressed air produced by the machine itself



Weight of main machine

27kg

Overall dimensions(L*W*H

746*315*229mm

Cylinder diameter*stroke of piston

Φ58*70mm

Rotation speed of engine

≥2450rpm

Displacement of engine piston

185cm³

Type of carburetor

hand needle valve, float-less type

Ignition system

controllable silicon, contact-less system

Drilling speed (mean value of five holes)

≥250mm/min

Drilling hole diameter

Φ28-42mm

Max drilling depth

6m

Fuel consumption

≤0.12L/m

Tank capacity

≥1.5liter

Drill rod and breaker shank

Hex22*108mm

Rotating speed of drill rod

≥200rounds/min

Clearance of spark plug

0.5-0.7mm



Handheld Gasoline Power  YN27C Internal Combustion Rock Drill For Mine Or Quarry 0



Handheld Gasoline Power  YN27C Internal Combustion Rock Drill For Mine Or Quarry 1Handheld Gasoline Power  YN27C Internal Combustion Rock Drill For Mine Or Quarry 2



Company Profile:



Hebei Minetech Machinery Technology Co, Ltd. is located in Hebei province of China. Our company is a professional production and export tapered and thread rod, chisel and button bit and other mining drilling tools enterprises. With our rich experience for over a decade and with professional engineers and sales team, we focus on providing complete solutions for mining machinery.



Handheld Gasoline Power  YN27C Internal Combustion Rock Drill For Mine Or Quarry 3Handheld Gasoline Power  YN27C Internal Combustion Rock Drill For Mine Or Quarry 4Handheld Gasoline Power  YN27C Internal Combustion Rock Drill For Mine Or Quarry 5



The  information you may like to know before order



1. Methods of Payment:

T/T (Telegraphic Transfer) or Western Union or L/C at sight

2. Handling time for an order

Within 10 days supplied from stock

3. Shipping way

Sample order: we suggest Courier express like DHL/UPS/TNT/FEDEX or by air

Bulk order: we suggest by air or by sea.

4. Quality Control

We have our own experienced QC.

There will be strict inspection and testing for every order before shipping out.

5. After Services:

a. Our sales team will response for your question within 24 hours (Holidays Excluded)

b. Technical Support will be available in any time

c. Free replacement will provide once the failure confirmed caused by our product quality
