Product Details:
|
| Product Name: | Diamond Core Drill Bit | Advantage: | High Drilling Efficiency,High-efficiency |
|---|---|---|---|
| Color: | Blue / Green / Orange / Red / Purple | Size: | AQ BQ NQ HQ PQ NQ3 HQ3 PQ3 |
| Use: | Geological Drilling | Machine Type: | Drilling Equipment |
| Packing: | Plastic Box,diamond Core Drill Bits Packed By Box Or Carton | ||
| High Light: | NQ2 50mm diamond core drill bit,50mm diamond core drill bit |
||
NQ Geological Mining Diamond Core Drill Bit for Hard Rock Core Drilling Tools
Product information:
The synthetic diamond poly crystalline is manufactured by sintering the fine grains of synthetic mono crystals and at high temperature and high-pressure.Because of their advantages of high wear ability,hot hardness high compressive and impact strength,It is widely used in geological exploration,petroleum drilling,mechanical processes,and so on.
Specifications:
| Size | Outside diameter(mm) | Inside diameter(mm) |
| AQ | 47.75/47.50 | 27.10/26.85 |
| BQ | 59.69/59.44 | 36.52/36.27 |
| BQ3 | 59.69/59.44 | 33.65/33.40 |
| NQ | 75.44/75.19 | 47.75/47.50 |
| NQ2 | 75.44/75.19 | 50.80/50.55 |
| NQ3, NQTT | 75.44/75.19 | 45.21/44.96 |
| HQ | 95.76/95.38 | 63.63/63.38 |
| HQ3, HQTT | 95.76/95.38 | 61.24/60.99 |
| PQ | 122.30/121.80 | 85.09/84.84 |
| PQ3 | 122.30/121.80 | 83.18/82.93 |
Application:
Diamond core bits are widely used in the drilling for geological exploration,water conservancy and power engineering,hydro geological exploration and building construction,etc.
Advantage:
High cost performance,High penetration rate and drilling efficiency,Long service life.
