Product Details:
|
| Name: | Rock Drill | Machine Type: | Drilling Tools |
|---|---|---|---|
| Model: | YT 24 | Application: | It Is Best Suited For Use In Medium And Small Mines. |
| Power Type: | Pneumatic | Weight: | 24kg |
| Advantage: | Light Weight, Low Noise, High Efficiency, Good Economic Results. | Piston Stroke: | 60mm |
| Length: | 668mm | Color: | Yellow,green,black |
| Shank: | 22×108±1 | Perforating Depth: | 5m |
| High Light: | yt24 pneumatic rock hammer,Perforador Nuematica yt24 rock drill,pneumatic yt24 rock drill |
||
Perforador Nuematica Rock Drill YT24 with Air Leg Rock Drilling Machine
Product Information:
The YT24 air-legged rock drill is a relatively early and definitive product in China. Compare with the same type of rock drills, YT24 has its unique advantage: light quality, low noise, high efficiency and good economic results.
Specifications:
| PRODUCT SPECIFICATION | ||
| The parameter name | Unit | The parameter value |
| Weight | kg | ≈24 |
| Length | mm | 668 |
| The cylinder diameter | mm | 80 |
| Piston stroke | mm | 60 |
| Gas consumption | L/s | ≤66.7 |
| Drilling and frequency | Hz | ≥31 |
| Impact energy | J | ≥75.5 |
| borehole speed | mm/min | ≥475 |
| The borehole diameter | mm | Φ34-42 |
| Perforating depth | m | 5 |
| Shank | mm | 22×108±1 |
| FT160A | FT160B | FT160C | FT170 | |
| Weight | 17 kg | 16 kg | 18 kg | 18 kg |
| Length | 1668 mm | 1428 mm | 1820 mm | 1668 mm |
| Propulsion Stroke | 1338 mm | 1098 mm | 1490 mm | 1338 mm |
| Cylinder Inner Diameter | 65 mm | 65 mm | 65 mm | 67 mm |
Features:
Light weight, low noise, high efficiency, good economic results.
